Design Specifications:
Size: DN8-DN65(1/4"-2 1/2")
Connection Type: Threaed, Welded, Tri-clamp, Flanged,
other types for customazied consultation
Operating Pressure: 0-16bar (0-232Psi)
Medium Temperature:-10°C~180°C
Minimum Opening Pressure: 30-40mbar
Working Principle：
The medium enters the valve body through the inlet port and pushes the valve stem and disc upward to open the valve.When backflow occurs from the outlet port, the valve disc and stem are quickly returned by the spring force and medium pressure,
ensuring rapid valve closure.
